Foxeer Digisight 2 Nano 720P Digital/Analog 4ms Latency Super WDR FPV Camera

Foxeer Digisight 2 Nano 720P Digital/Analog 4ms Latency Super WDR FPV Camera

Check out all our FPV Cameras and the rest of our Foxeer Products!

Specifications:

• Sensor Type Sony 1/3″ CMOS Sensor
• Scale 4:3(default)/16:9 Switchable
• Tv System PAL(default)/NTSC Switchable
• Resolution Digital 720P/Analog 1000TVL
• Shutter Speed PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec
• Video Output 720P Digital HD/CVBS Analog Signal
• Digital: FOV-H:120° FOV-D: 145°
• Analog: FOV-H:125° FOV-D: 155°
• Shutter Speed Auto
• Minimum Illumination 0.01Lux
• White Balance Auto
• DNR 3DNR 2DNR
• WDR 120dB
• Mode DAY/CLOUDY/Night/LED
• Fast Mode Switch Long Press Right Button to switch among DAY/CLOUDY/Night/LED
• Flight OSD Cam Title / Voltage (Only in analog) / Time
• Digital: 3.3V from VTx
• Analog: 4.5~20V
• Working Temperature -10°~50°C RH90% MAX
• Working Humidity 20~80%
• Storage Temperature -20°~70°C
• Menu Analog via camera programming board, Digital via VTx and Cam board
• Analog:50mA±15% @ DC12V 115mA±15% @ DC5V
• Digital:350mA@3.3V(Powered by VTX)
• Cable Length 150mm
• Dimension 14*14mm; 19*19mm(Add Bracket)
• Weight 4.3g(Exclude cable)

Package Includes:

• 1 x Foxeer Digisight 2 Nano 720P Digital Analog 4ms Latency Super WDR FPV Camera
