HappyModel Crazybee F4 Lite 1S Whoop Flight Controller for Mobula 6 – Frsky
$82.99
| Weight | 0.028 kg |
|---|
Out of stock
Description
Replacement flight controller for the popular Happymodel Mobula 6 or any 1S build
Checkout our Mobula 6 parts and our full collection of Happymodel Products!
Specifications
Flight Controller
- (Frsky SPI RX version) CRAZYBEE F4 Lite Frsky version Firmware target: CrazybeeF4FR
- (Flysky SPI RX version) CRAZYBEE F4 Lite Flysky version Firmware target: CrazybeeF4FS
- MCU:STM32F411CEU6 (100MHZ, 512K FLASH)
- Sensor: MPU-6000(SPI connection)
- Board size: 28.5 * 28.5MM
- Power supply: 1S battery input (DC 2.9V-4.35V)
- Built-in 5A(each) Blheli_S 4in1 ESC Dshot600 ready
- Built-in Betaflight OSD(SPI Control)
- Built-in 5.8G VTX
- Built-in SPI Frsky/Flysky receiver
- Built-in 5V 1A BEC
- Built-in voltage detection
Onboard 4in1 ESC
- MCU upgraded to EFM8BB21
- Power supply: 1S LiPo/LiPo HV
- Current: 5A continuous peak 6A (3 seconds)
- Support BLHeliSuite programmable
- Factory firmware: O_H_5_REV16_7.HEX
- Default protocol: DSHOT600
Onboard FrSky SPI D8 Receiver Version
- SPI BUS receiver Frsky D8 compatible
- Compatible Non EU transmitter D8 model
- Channels: 8ch
- Failsafe support
- No ground interference ( Transmitter and receiver 1 m from the ground): 100m~200m
Onboard 5.8GHz VTX
- Output power: 25mw
- Frequency: 40CH
- Input voltage: 3.3V 5.5V
- Current consumption: 300mA(type)
- Frequency: 5.8GHz 5bands 40 channels
- With Race band
- Smartaudio ready
Includes
- 1x HappyModel Crazybee F4 Lite 1S Whoop Flight Controller
