TBS Grinder V4 2207 1750KV Freestyle Motor
$27.99
| Weight | 0.044 kg |
|---|
Out of stock
Description
🚀 Looking for an alternative?
This Tbs item is currently out of stock or discontinued. We highly recommend checking out our premium in-stock alternatives from top brands like T-Motor, GEPRC, and iFlight in the Motors section!
This Tbs item is currently out of stock or discontinued. We highly recommend checking out our premium in-stock alternatives from top brands like T-Motor, GEPRC, and iFlight in the Motors section!
The final form of the botgrinder motors are here! Introducing the v4 grinder motors! Redesigned with the ultimate durability in mind these new motors feature a new bearing reinforcement and a super thicc 4mm shaft to make these the strongest grinder motors yet!
Check out all our 22xx Motors and the rest of our TBS collection!
Specifications
- Stator Size (Diameter): 22mm*7mm
- Kv: 1750kv
- Magnets N52SH: Curved
- Windings: 10.5 turn DLRK
- Shaft Length (mm): 11.5mm
- Shaft Diameter (mm): 3mm
- Shaft material: Steel
- Bearing: NSK684
- Weight (With Wires) (g): 34.5g
- Cells (Lipo): 4S-6S
- Max Current (A): 45A
- Max Burst Current (A): 50A
- Internal Resistance (Rm): 50Ω
- Wire Spec (AWG): 20#
- Base Mounting Pattern: 16x16mm
- Base Mounting Thread: M3 Thread
- Motor Overall Dimensions: φ27.5mm*18.8mm
Package Includes:
1 x TBS Grinder V4 2207 1750KV Freestyle Motor
