4K Intelligent Full-Color Night Vision Thermal Imaging Camera for UAVs

Xianfei Z-2Mini Core Technical Specifications

Core Imaging & Gimbal Performance

• Official Model: Xianfei Z-2Mini Intelligent Dual-Sensor Micro Gimbal
• Gimbal Stabilization: 3-Axis High-Precision Brushless Gimbal (anti-vibration, jitter-free imaging in high-speed flight)
• Dual-Sensor Imaging System:
  • Visible Light Camera: 1/2.8″ CMOS Sensor, 4K@30fps Ultra HD Video, 8MP Static Photos, Full-Color Night Vision Mode (0.001Lux ultra-low light performance)
  • Thermal Imaging Sensor: High-Sensitivity Uncooled Infrared Detector, 256×192 Resolution, 8μm~14μm Spectral Range, Digital Zoom, Temperature Measurement Support
• AI Intelligent Functions: Smart Target Tracking, Human/Vehicle/Animal Recognition, Motion Detection, Abnormal Heat Source Alert
• Video Output: H.265/H.264 Encoding, RTSP/ONVIF Protocol Support, Real-Time Video Transmission
• Control Interface: UART, CAN Bus, PWM, Compatible with Mainstream Flight Controllers (Betaflight, INAV, ArduPilot, PX4)
• Power Supply: 12V-25V Wide Voltage Input, ≤8W Full Load Power Consumption
• Net Weight: ≤120g (ultra-lightweight, minimal impact on drone flight time)
• Operating Temperature Range: -20℃ ~ 60℃, IP54 Dust & Water Resistant
• Dimensions: 48mm × 45mm × 42mm (ultra-compact form factor for mini drones)

Key Features & Benefits of Xianfei Z-2Mini Dual-Sensor Gimbal

• Dual-Sensor All-Weather Imaging Capability: Integrates a 4K ultra HD visible light camera and high-sensitivity thermal imaging sensor, delivering all-weather, day-and-night imaging performance. The advanced full-color night vision mode captures crisp, color-accurate footage in ultra-low light conditions (down to 0.001Lux), while the thermal sensor penetrates darkness, fog, smoke, and foliage to detect heat signatures, making it ideal for 24/7 operations.
• 3-Axis High-Precision Stabilization: High-performance brushless 3-axis gimbal with advanced anti-vibration algorithm eliminates jitter and shake during high-speed flight, aggressive maneuvers, and windy conditions, delivering smooth, cinema-grade stable video and sharp photos. The compact design maintains full stabilization without adding excess payload weight to your drone.
• AI-Powered Intelligent Functions for Industrial Operations: Built-in AI deep learning algorithm supports smart target tracking, human/vehicle/animal recognition, abnormal heat source detection, and motion alert. The system can automatically lock onto and track moving targets, and send real-time alerts for abnormal heat signatures, making it an essential tool for industrial inspection, security surveillance, and search & rescue missions.
• Ultra-Lightweight Ultra-Compact Design for Mini Drones: Weighs only ≤120g with an ultra-compact 48×45×42mm form factor, perfectly optimized for compact and mini UAV platforms. The minimal payload weight has negligible impact on drone flight time and maneuverability, making it the ideal dual-sensor payload for small industrial and commercial drones.
• Wide Compatibility & Flexible Integration: 12V-25V wide voltage input and multi-interface support (UART, CAN Bus, PWM) ensure seamless integration with all mainstream flight controllers, including Betaflight, INAV, ArduPilot, and PX4. The system supports standard RTSP/ONVIF protocols, making it compatible with most industrial UAV ground control stations and video transmission systems.
• Rugged All-Weather Industrial Design: IP54 dust and water resistant rating, with a wide -20℃ to 60℃ operating temperature range, built to withstand harsh outdoor environments – from high-altitude cold to hot desert conditions, rainy and foggy weather, and industrial inspection scenarios. The rugged construction ensures reliable long-term operation in demanding field conditions.
• Versatile Multi-Scenario Application Support: The dual-sensor design and intelligent functions make this gimbal suitable for a wide range of professional applications, including power line/pipeline/photovoltaic inspection, public security & law enforcement surveillance, fire fighting & emergency rescue, wildlife monitoring, agricultural crop health assessment, and night-time aerial surveying.

Ideal Applications & Use Cases

The Xianfei Z-2Mini dual-sensor micro gimbal is an essential payload for professional UAV operators across industries, including:

• • Power Line, Pipeline, and Solar Farm Industrial Inspection
  • Public Security, Law Enforcement, and Border Patrol Surveillance
  • Fire Fighting, Search & Rescue, and Emergency Response
  • Wildlife Monitoring and Ecological Protection
  • Agricultural Crop Health Assessment and Precision Farming
  • Urban Management and Illegal Construction Monitoring

• Night-Time Aerial Surveying and Mapping
• Recreational Long-Range FPV and Night Flight

Installation & Compatibility Guide

• Drone Compatibility: This gimbal is compatible with all mainstream multi-rotor drones with a payload capacity ≥150g, including custom industrial UAVs, commercial inspection drones, and long-range FPV platforms. It is not limited to specific drone brands, with flexible integration for most UAV platforms.
• Mounting & Installation: The gimbal features a standard M3 mounting hole pattern for easy installation on drone gimbal dampers. The package includes all necessary mounting hardware and cables for plug-and-play setup, with a detailed user manual for step-by-step installation guidance.
• Flight Controller Integration: Connect to your flight controller via UART/CAN bus for gimbal control, target tracking, and telemetry integration. The system is fully compatible with Betaflight, INAV, ArduPilot, and PX4 firmware, with pre-configured parameters for quick setup.
• Video Transmission Integration: The gimbal supports standard H.265/H.264 video output, compatible with all mainstream digital video transmission systems (including DJI O3/O4 Pro, HDZero, Walksnail Avatar) for real-time video downlink to your ground station or FPV goggles.

Frequently Asked Questions (FAQs)

What is the weight of the Xianfei Z-2Mini gimbal?

The Xianfei Z-2Mini dual-sensor micro gimbal weighs ≤120g, with an ultra-compact form factor optimized for mini and compact UAV platforms, with minimal impact on drone flight time and maneuverability.

What is the night vision performance of the Xianfei Z-2Mini?

The Xianfei Z-2Mini features an advanced full-color night vision mode with ultra-low light performance down to 0.001Lux, delivering crisp, color-accurate footage in near-total darkness. The integrated thermal imaging sensor penetrates darkness, fog, smoke, and foliage to detect heat signatures, for reliable 24/7 operation.

What drones is the Xianfei Z-2Mini compatible with?

The Xianfei Z-2Mini is compatible with all mainstream multi-rotor drones with a payload capacity ≥150g, including custom industrial UAVs, commercial inspection drones, and long-range FPV platforms. It supports all mainstream flight controllers (Betaflight, INAV, ArduPilot, PX4) and video transmission systems, with flexible integration for most UAV platforms.

Does the Xianfei Z-2Mini support AI target tracking?

Yes. The Xianfei Z-2Mini features a built-in AI deep learning algorithm that supports smart target tracking, human/vehicle/animal recognition, abnormal heat source detection, and motion alerts. The system can automatically lock onto and track moving targets, with real-time alerting for abnormal conditions.

What is the thermal imaging resolution of the Xianfei Z-2Mini?

The Xianfei Z-2Mini is equipped with a high-sensitivity uncooled infrared thermal detector with 256×192 resolution, 8μm~14μm spectral range, and supports digital zoom and temperature measurement, making it ideal for industrial inspection, heat source detection, and search & rescue operations.

Is the Xianfei Z-2Mini weather resistant?

Yes. The Xianfei Z-2Mini features an IP54 dust and water resistant rating, with a wide -20℃ to 60℃ operating temperature range, built to withstand harsh outdoor environments and all-weather operation in demanding field conditions.

What is the maximum video resolution of the Xianfei Z-2Mini?

The visible light camera of the Xianfei Z-2Mini supports up to 4K@30fps ultra HD video recording and 8MP static photos, with H.265/H.264 encoding for efficient video compression and real-time transmission.
