ZOHD DART 250G 570mm EPP FPV Wing – PNP Version

Based on the great reputation of the Dart Wing family and the invaluable info gathered from top world-wide FPV pilots, SonicModell was able to develop new techniques, and after tons of tests and refinements, we are finally bringing you the finest sub-250 ship in the market: The ZOHD Dart250G.

Using our default configuration and the recommended FPV gear, it is 100% under 250 grams. To the untrained eye, she will look like a harmless toy but, -we and you know- this is a super capable FPV ship that will even let you do long-range like the bigger sisters. Being so light, it’s a blessing for beginners since they will find that is really hard to break it. Also, coupled with our NEW Kopilot Lite and the VC400 camera, you will get a ready to go FPV system, solder and hassle-free.

Now you can enjoy more than 30 minutes FPV action (with a 18650 2S1P 3500mAh) or a super thrilling proximity mission (on 3S setup), everything under 250 grams!

Don’t forget to check out the rest of our Fixed Wing Planes.

Features:

• AUW is less than 250g, ideal to comply with Sub 250g regulations
• Durable EPP material, built-in CF spar for enhancement, crash-resistant
• Being light-weight will be safe to fly anywhere, anytime. You’re avoiding the hassle of an FPV registration
• Glue-free assembly, the main wing, and tails come with pre-applied 3M adhesive, just peel it off and install them
•  Large battery bay for extended flight time
• Nose camera bay compatible with all FPV and AIO cameras in the market
• Teflon cover for the fuselage bottom, super durable, protecting the fuselage bottom from scratches
• Servo arms are well protected by an EPP hump
• Built-in CF rod in the ailerons will give precision and sharp action to your inputs
• Dedicated equipment bay for Flight Controller and GPS
• Main wing leading edge cover for those unexpected impacts
• Textured areas on both side of the fuselage, for more secure hand launch grip
• The optimized air-cooling design will keep your gear safe from overheating

Specifications:

• Material: High-quality EPP
• Wingspan: 570mm ( 22.44 inches )
• Length: 379mm ( 14.92 inches )

Option A (2S Version)

• Motor: 1406 – 2600KV
• ESC: 30A with 5V 2A BEC
• Servos: 9g
• Propeller: 2 blade 5 x 5
• Recommended Battery: Lipo 2S 900 – 1500mAh, Li-ion 18650 2S1P 3500mAh

Option B (3S Version )

• Motor: 1406 – 2600KV
• ESC: 30A with 5V 2A BEC
• Servos: 9g
• Propeller: 3 blade 3 x 5 x 3
• Recommended Battery: Lipo 3S 800 – 1500mAh

Download the user Manual here

Package Includes:

• 1 x ZOHD Dart 250G RC Airplane
• 1 x Motor: 1406 – 2600KV
• 1 x ESC: 30A with 5V 2A BEC
• 1 x Servos: 9g
• 1 x Propeller: 3 blade 3 x 5 x 3 and 2 blade 5 x 5
• 1 x Manual
