Holybro Kopis cinematic X8 is a powerful and heavy-duty model designed for professionals. With a full carbon fiber frame that provides a good shock absorption performance, Kopis Cinematic X8 offers a perfect platform with adjustable installation angles available from 0 to 25 °. for both SLR and HD cameras such as Comodo; zcam-e2; Sony a7s3 and Panasonic S5, etc. With redundant configurations of ESC and motor supported, best performance and security are both ensured. DJI FPV air unit digital VTx system installation seat has been reserved.
Two pieces of 5mm carbon fiber arms provide reliable structural support for this powerful quad. We also have new versions of Holybro KAKUTE H7 V2, KAKUTE H7 Mini, KAKUTE F7 V1.5, KAKUTE F7 HDV, and KAKUTE F7 Mini V3 which are compatible with X8.

Check Out all our Cinelifters and related Accessories as well as the rest of our Holybro Products

30110 ARF Kit 1

Features:

Propeller: Gemfan 7040 7 Inch 3-Blade Propellers
Motor: T-Motor F90 KV1300 Motors
Arm: 16mm wide x 10mm thick (with 5mm thick carbon fiber boards overlaid)
Landing gear: TPU bracket combined with 10 mm carbon fiber tube
Compatible with DJI Air Unit & Caddx Vista HD Digital System
Compatible with multiple mounting holes: 30.5×30.5mm & 20x20mm
Professional camera installation supported: Komodo, ZCAM, BMPCC, etc
Camera platform shock absorption structure with 10 silicone damping balls
Spacing between top and bottom plates: 22mm
Camera platform elevation: 0 ~ 25 ° Adjustable
Wheelbase: 396mm
Weight: 1124g
Frame weight: 640g

Recommended Equipment：

FC: KAKUTE H7 v2
ESC: Tekko32 F4 4in1 50A ESC / Tekko32 F4 Metal 4in1 65A ESC
VTx: DJI FPV Air Unit / CADDX Vista Kit

Battery Recommendation: 6s 5000mAh
Payload Capacity: 1.5kg
Flight Time: 5 minutes (with 1.5kg payload) | 11 minutes (without payload)

Note: Flight time was tested using a 6s 5000mAh battery with 2806.5 1300kv motor & 7040 props. Flight time may vary depending on payload and battery size.

Download Kopis_Cinematic_X8_Assembly_Guide

3D Print: Kopis_Cinematic_X8_3D_Print_STL_Files.rar

Package Includes:

1 x Kopis Cinematic X8 Frame Kit
